Many civil engineering projects require the use of fill material. Whenever soil is placed as an engineering fill, it is usually compacted to a dense state, to obtain satisfactory engineering properties. Compaction on site is is usually effected by mechanical means such as rolling, ramming or vibrating. Control of compaction is necessary to achieve a satisfactory result at a reasonable cost. Laboratory compaction tests provide the basis for control procedures used on site.

This spring-type penetrometer can be used in the field to control soil compaction. The stem is calibrated to 150 lbf x 2 lbf divisions, and a sliding collar indicates the applied load. A rapid estimate of the moisture content of soil can be obtained by comparing the amount of penetration of the needle for a corresponding load, with a laboratory determined moisture/density curve for a similar soil.

Model No. Desc
29-3933 Case for Proctor Penetrometer
29-3925 Proctor Penetrometer - complete with set of needle points

In this method of determining the dry density of in-situ soil, a core-cutter of known volume is driven into the soil by a rammer. The core-cutter is removed, trimmed and the soil obtained is weighed and dried for a moisture/density check.

Model No. Desc
29-5340 Driving Rammer
29-5320 Driving Dolly
29-5300 Core Cutter 100mm
