Date posted: 27th March 2018 14:28
ELE International are pleased to announce a software enhancement for the DSU. This enhancement now allows Automatic CBR tests to be supported with the Tritest frame, as well as existing manual CBR tests, and user tests. Other updates have also improved overall user experience.
The parts required:
DSU 27-1300/01, /02 https://www.ele.com/Category/data-logging-software-and-electronic-instrumentation
Tritest 50 25-3518/01 (with E-stop) https://www.ele.com/Product/digital-tritest-50-load-frame
Normal CBR moulds and accessories https://www.ele.com/Subcategory/cbr-moulds-and-accessories
Penetration piston 24-9182 https://www.ele.com/Product/penetration-piston
Bracket and adapter 24-9188 https://www.ele.com/Product/bracket-and-adaptor-dual-purpose-mounting-bracket-for-cbr-penetration-gauges-el24-9184-el24-9186
Appropriately sizes S Type load cell https://www.ele.com/Subcategory/instrumentation-for-triaxial-testing
CBR Displacement Transducer 27-1705 https://www.ele.com/Product/cbr-penetration-transducer-50mm-travel-fitted-with-5-pin-din-plug-
Adapter kit CBR on Tritest (25-3518/10) ) https://www.ele.com/Product/adaptor-kit-to-perform-cbr-on-the-tritest-50-load-frame
Please note that it is only compatible with the most recent Tritest 50 model with the E-stop.
