Master Humidifier

34-6775/02

Category:

Concrete

Sub Category:

Fresh and Hardened Concrete Testing, Curing of Specimens

Product Group:

Master Humidifier

Ultrasonic humidifiers produce a mist created by a piezo-electric device which produces an extremely fine, smoke-like fog. The vapor is dispensed by a small internal fan through an opening in the front or top of the unit. This fog travels just a few feet before evaporating into the surrounding atmosphere. Inside there is a small float valve and the p/e device which creates the fog by means of ultrasonic vibration of the water.



120vAC, 60 Hz, 1ø. 340 Watts.

Operating Water Pressure, psig 10-100
Description Master Humidifier



Specifications

Discharge Horizontal Discharge
Output 7.5 lbs. vapor/hr. (3.4 kg/hr.); up to 6 ft. (2 m) horizontally.
Particle Size 4-7 microns
Motor Sealed, ball-bearing type.
Sound Level Approx. 48dB
Water Supply 1/4" push-in fitting (on left rear).
Operating Water Pressure 10-70 psi
Dimensions 18 -1/4” W x 7-1/4" D x 11-3/4" H
Weight Net 38 lbs. (17.3 kg).
